PHILADELPHIA STREETS DEPARTMENT, SURVEY AND DESIGNS BUREAU

Frank Morelli
Survey Bureau Manager
Philadelphia Streets Dept.

Phone: (215) 686-5540
Email: frank.morelli@phila.gov



Plan, Plan revising the lines and grades of such portions of City Plans # 356, 357, 368 & 387 as may be necessary to permit the improvement of Essington Ave. from 90th St. to Island Ave. and the construction of a traffic circle at the intersection of Essington Ave. and Island Ave. 40th Ward, Philadelphia [Ordinance March 19, 1943; confirmed June 1, 1943] , 1943

Original size: 16 x 65 in. (estimated)
